Product Description
Product description:
●Modular cylinder
Enhanced identity, More reliable material, Max. working temperature 120 ℃， the special structure reduces leakage problem
●Vacuum generator, Smart design,30% higher efficiency than other brands.
Specification:
| Tank capacity | 30L |
| Air inlet pressure | 6-8Bar |
| Air inlet connection | 1/4” |
| Collection bowl capacity | 9/10L |
| Vacuum degree | -1~0Bar |
| Air pressure for oil discharge | 0.7-1Bar |
| Oil temperature range | 40-60℃ |
| Suction speed(max.) | 6.5L/m |
| N/G weight | 13/14.5kgs |
| Package dimension | 490*440*1000mm |
